2022 Yamaha YZ125X

  • 2022 Yamaha YZ125X
  • 2022 Yamaha YZ125X
  • 2022 Yamaha YZ125X
  • 2022 Yamaha YZ125X
  • 2022 Yamaha YZ125X
  • 2022 Yamaha YZ125X
  • 2022 Yamaha YZ125X
  • 2022 Yamaha YZ125X
  • Video Button Maxresdefault
Videos
Call for Price
 Get a Quote  Get Financed  Value a Trade  Contact Us  Book a Demo   Get Directions  Print
Overview

Light, fast and fun! The high performance two-stroke entry into the world of XC and enduro competition. Designed to be the perfect stepping stone toward a full size cross-country machine, the YZ125X is the pinnacle of lightweight, two-stroke performance on the race course.

Specifications
Model
YZ125X
Category Name
Motorcycles
Year
2022
Sale Type
New
Manufacturer
Yamaha
Color
Team Yamaha Blue
Engine Size
125 cc
Width
825 mm (32.5")
Engine
2-stroke, liquid-cooled, reed-valve, single
Height
1,285 mm (50.6")
Length
2,140 mm (84.3")
Colour(s)
Yamaha Racing Blue
Wheelbase
1,455 mm (57.3")
Wet Weight
94 kg (209 lb)
Final Drive
Chain
Lubrication
Wet sump
Seat Height
955 mm (37.6")
Tires (Rear)
110/90-18
Transmission
Constant mesh, 6-speed
Brakes (Rear)
245 mm disc / single piston caliper
Fuel Delivery
Mikuni TMX x 38
Fuel Capacity
8 litres (1.8 imp. gallons)
Tires (Front)
90/90-21
Brakes (Front)
270 mm floating disc / twin piston caliper
Bore And Stroke
54.0 x 54.5 mm
Ground Clearance
351 mm (13.8")
Compression Ratio
7.4~8.8:1
Suspension (Rear)
Fully adjustable link Monocross / 315 mm (12.4") wheel travel
Suspension (Front)
Fully adjustable 48 mm KYB inverted fork / 300 mm (11.8") travel
Ignition / Starting
CDI / Kick
highlights

Ra CROSS COUNTRY- TUNED YZ125 POWER

Based on the legendary 125cc liquid-cooled, reed-valve-inducted YZ two-stroke engine, the YZ125X utilizes a revised compression ratio, Yamaha Power Valve System (YPVS™) timing and a model-specific CDI unit—all focused on creating broad power delivery that suits off-road terrain and a wide range of rider skill levels.

Ra CROSS COUNTRY- SPECIFIC FEATURES

Cross country focused suspension setup and Dunlop® Geomax AT81 tires, 18-inch rear wheel, sealed O-ring chain, a standard side stand and fuel tank petcock with reserve position are perfect for GNCC® racing.

TWO STROKE AGILITY Ra

The YZ125X is optimized for the unique demands of Hare Scrambles and GNCC® racing. The YPVS™-equipped 125cc two-stroke engine is mated to a six-speed transmission for the ultimate cross country powerplant.
features and benefits

Key Features ​

  • YZ125 two-stroke engine with Yamaha Power Valve System (YPVS)
  • Model-specific CDI unit
  • Racing intake system
  • Ultra-lightweight YZ125-spec frame
  • Industry-leading, XC-specific adjustable KYB suspension
  • Smooth shifting, 6-speed, close ratio transmission
  • YZ125 two-stroke engine with Yamaha Power Valve System (YPVS)
  • Model-specific CDI unit
  • Racing intake system
  • Ultra-lightweight YZ125-spec frame
  • Industry-leading, XC-specific adjustable KYB suspension
  • Smooth shifting, 6-speed, close ratio transmission
  • "Gripper" type seat and narrow fuel tank
  • Adjustable, tapered aluminum handlebar
  • 18-inch rear wheel and large rear sprocket

Engine

  • Liquid-cooled, 125 cc, crankcase reed valve-inducted 2-stroke engine provides class leading power and acceleration.
    • super crisp, instant "right now" engine power (when in the powerband)
    • easy and economical to maintain, service and rebuild
  • 7.5-degree cylinder angle and straight shot intake path through the combustion chamber.
    • maximum power output
  • Ceramic composite cylinder bore is a linerless design with the ceramic coating sprayed directly on the aluminum block.
    • reduced weight (no heavy iron liner)
    • reduced friction
    • extended cylinder life
    • excellent heat dissipation for consistent power delivery
  • Specially designed combustion chamber achieves a more complete burn at higher rpm.
    • class-leading power
  • Lightweight, flat-top forged aluminum piston.
    • excellent durability
    • light weight means fast engine response
    • matches combustion chamber design for maximum power delivery
  • Lightweight, ball-bearing-style crank.
    • lightweight design for fast throttle response
    • friction-reducing crank seals
  • Compact crankcases.
    • lightweight design
    • helps centralize mass
  • Quick-access, magnesium outer (sub) clutch cover.
    • lightweight design
    • speeds clutch access
  • Close-ratio, 6-speed transmission uses optimized gear ratios.
    • ratios are matched to engine output for maximum performance
    • optimal hook-up for outstanding acceleration and corner-exiting power
    • transmission features "involute splines" for smooth, positive shifting even under power
  • Yamaha's patented YPVS system.
    • features a slide (guillotine) type power valve that provides the benefits of both solid, low-rpm power delivery combined with a strong top-end punch. This system varies the exhaust port height and timing based on engine rpm.
  • Mikuni TMXx38 carburetor features a "D" slide design.
    • enhances overall power delivery
    • provides crisp throttle response at all rpm
  • 6-petal, carbon fibre reed design.
    • for stronger high-rpm performance with greater over-rev capacity
  • CD (capacitor discharge) ignition system.
    • delivers a precise spark for fast, sure starts
    • ensures optimal timing at all rpm for fast, strong response
  • High-capacity, washable, dual-stage, foam air filter.
    • excellent filtering qualities
    • reusable filter reduces maintenance costs
  • Large-capacity, dual radiators feature 10-row cores.
    • maximum cooling efficiency
  • Lightweight exhaust system features a re-packable aluminum silencer which allows the rider/tuner to maintain the correct amount of back pressure for maximum engine performance while reducing noise.
  • Works-style clutch lever and race-spec barrel adjuster.
    • easy lever pull
    • for on-the-fly clutch adjustments

Chassis/Suspension

  • Lightweight, aluminum, semi-double-cradle frame.
    • combines with compact engine to provide an awesome power to weight ratio
    • obvious benefit of an aluminum frame is a significant weight reduction
    • Yamaha maintains semi-double cradle design because it offers an excellent rigidity balance between lateral and torsional rigidity while offering controlled flex in the longitudinal plane
    • result is a light aluminum frame, which provides excellent handling, good ride quality, excellent stability and responsive cornering performance
  • Removable rear subframe.
    • constructed of square-section, lightweight aluminum
    • detachable design allows easy access when servicing rear suspension components
  • Lightweight, tapered design aluminum swingarm.
    • produced by "hydro forming", a forming method that uses high pressure water to form shapes
    • excellent rear wheel traction and control
    • lightweight design
  • Cast aluminum upper and forged lower triple clamps.
    • strong yet lightweight
    • fast, agile handling
  • Adjustable handlebar mounts.
    • handlebar can be moved 10 mm rearward if desired
  • "Speed Sensitive System" 48 mm, adjustable, inverted, "twin chamber" KYB fork. Front wheel travel is 300 mm (11.8").
    • fork adjustments include: 20-way compression damping and 20-way rebound damping
    • optional fork springs are available through Genuine Yamaha parts
    • low-friction fork seals provide reduced stiction for a smoother stroke
    • twin-chamber design means the damper unit is in a separate structure which prevents aerated fork oil from entering the inner damper assembly and degrading its damping abilities
    • the inner damper is pressurized, it also eliminates bubbles forming in the oil
    • "Speed Sensitive" design means the damping force is controlled by piston speed, not position in the fork
  • Fork also features a Transfer Control Valve (TCV).
    • TCV enhances damping from mid to full stroke and improves bottoming characteristics
    • TCV offers more precise control throughout the full suspension stroke
    • TCV is located on the upside of the spring and its function is controlled by piston speed, not piston position, hence the term "Speed Sensitive System fork"
  • Large wrap-around plastic fork protectors.
    • provide excellent protection from dirt, mud and stone chips
    • self-supporting design reduces friction for smoother stroke
  • Monocross link rear suspension features a fully adjustable, KYB piggyback shock which provides 315 mm (12.4") of wheel travel.
    • features separate adjusters for high- and low-speed compression damping
    • adjustments include: spring preload, 20-way rebound damping, 20-way low-speed compression damping and 2 turns of high speed compression damping
    • 18 mm damper rod
    • Kashima coating (friction reducer) is used in the shock body and sub tank to reduce friction and improve suspension performance
    • piggyback shock utilizes a full rebound oil lock system for excellent suspension function and great ride quality.
  • 270 mm floating front disc brake with Nissin twin piston caliper.
    • "wave" style rotor (disc) reduces weight, improves cooling (more surface area) and improves styling
    • braking performance is excellent with great feel and control
  • "Shorty" front brake lever is adjustable for various hand sizes.
  • 245 mm rear disc brake with single piston caliper.
    • integrated master cylinder (fluid reservoir is integrated into the top of the master cylinder)
    • "wave" style rotor (disc) reduces weight, improves cooling (more surface area) and improves styling
    • strong stopping power with excellent feel and control
  • Rugged, plastic rear caliper and lower rear disc protectors / guards.
  • Sun Star-brand rear sprocket.
    • increases the contact area between the sprocket and chain rollers
    • reduces the load on the chain and increases service life of chain and sprocket
  • Lightweight, D.I.D. 21" front and 18" rear rims and premium Dunlop tires.
    • provide excellent durability
    • reduces unsprung weight for optimal suspension performance and handling
  • Flat-design seat features multi-density foam.
    • provides good initial softness/comfort and then increases the firmness as more pressure is applied
    • "pebble" finish on the top and side surfaces provides excellent rider grip and durability
  • Seat, handlebar and fuel tank ergonomics provide excellent freedom of movement for the rider.

Details

  • Slim design, modern aggressive bodywork allows easy rider movements
  • Lightweight YZ250F/450F-based wide footpegs provide excellent grip & ground clearance
  • Heavy-duty 520 gold anodized "O" ring chain
  • Rugged chain guide helps prevent the chain from de-railing & also helps protect the rear sprocket
  • Serrated rear brake lever & folding shift lever tip
  • Stainless steel, inner clutch cable provides excellent strength, smooth action & long life
  • E10 friendly fuel system components
