2022 Kawasaki KLX140R F

  • 2022 Kawasaki KLX140R F
  • 2022 Kawasaki KLX140R F
  • 2022 Kawasaki KLX140R F
  • 2022 Kawasaki KLX140R F
  • 2022 Kawasaki KLX140R F
  • 2022 Kawasaki KLX140R F
  • 2022 Kawasaki KLX140R F
  • 2022 Kawasaki KLX140R F
Call for Price
 Get a Quote  Get Financed  Value a Trade  Contact Us  Book a Demo   Get Directions  Print
Overview
With an electric start, and confident handling, the KLX140R, KLX140R L and KLX140R F motorcycles are the ideal entry into off-road riding. The easy-to-ride KLX140R series offer a 144cc engine, plush suspension and a push button electric start, making for great trailblazers.

FEATURING

  • Push-button electric start
  • High-revving 144cc air-cooled, SOHC, four-stroke single
  • 5-speed transmission with manual clutch

ADDITIONAL VEHICLE FEATURES

  • Full-size wheels (F21”, R18”) and ground clearance (315 mm [12.4 in])
  • Adjustable long travel suspension
  • Disc brakes front and rear
Specifications
Model
KLX
Category Name
Motorcycles
Year
2022
Sale Type
New
Manufacturer
Kawasaki
Color
Lime Green
Engine Size
144cc
Full-size
wheels
Adjustable Long-travel
suspension
power
Clutch
Wet multi-disc, manual
Engine
144cc, air-cooled, 4-stroke, SOHC 2-valve single
Ignition
Digital DC-CDI
Starting
Electric
Induction
Piston reed valve
Final Drive
Chain
Fuel System
Carburettor: Keihin PB20
Lubrication
Forced lubrication, wet sump
Transmission
5-speed, return
Bore X Stroke
58.0 x 54.4 mm
Compression Ratio
9.5:1
details
Warranty
6 months
Wheelbase
1,330 mm (52.4 in)
Curb Mass**
99 kg (218 lb)
Seat Height
860 mm (33.9 in)
Fuel Capacity
5.8 litres
Road Clearance
315 mm (12.4 in)
Dimensions (L X W X H)
2,005 x 790 x 1,135 mm (78.9 x 31.1 x 44.7 in)
Kawasaki Protection Plus
12 / 24 / 36 / 48 months
performance
Frame
Perimeter, box-section, high-tensile steel
Rear Tire
4.10-18 59M
Front Tire
2.75-21 45M
Rear Brake
ø190 mm petal disc with single-piston caliper
Front Brake
Single ø220 mm petal disc with dual-piston caliper
Rake / Trail
27.0° / 116 mm
Steering Angle (L/R)
41° / 41°
Rear Suspension / Wheel Travel
Uni Trak, single shock with piggyback reservoir, adjustable compression and rebound damping, and adjustable spring preload / 200 mm (7.9 in)
Front Suspension / Wheel Travel
ø33 mm telescopic fork / 190 mm (7.5 in)
top features

CONFIDENT HANDLING

Power Fuels Fun

The lightweight box-section perimeter frame is made from high-tensile steel for exceptional rigidity and strength. The narrow profile contributes to an easier rider grip and smoother movement on the bike. Working together, the highly capable suspension and lightweight chassis deliver handling that exudes confidence.

    The KLX140R L features larger wheels (F19”, R16”), taller seat height (800 mm [31.5 in]) and higher 255 mm (10.0 in) ground clearance, while the KLX140R F features full-size wheels (F21”, R18”) and 315 mm (12.4 in) ground clearance.

SMOOTH POWER

Electric Start

The high-revving, 144cc, air-cooled SOHC 4-stroke single easily starts with the push of a button. The air-cooled engine eliminates the need for radiators while keeping the chassis slim and lightweight. The 5-speed transmission with manual clutch delivers smooth shifting and acceleration.

RELIABLE BRAKING

Front and Rear Disc Brakes

Front and rear disc brakes provide strong progressive stopping power. The 220 mm front petal disc with a dual-piston caliper is complemented by a 186 mm* rear petal disc with single-piston caliper, inspiring confidence on the trails.
*KLX140R F rear disc is 190 mm
